Request Information
Unit of Measure

Specifications

Manufacturer Stock

 N/A {0}

Brands

 N/A PUI Audio™

Manufacturer

 N/A PUI Audio�, Inc.

Direct Current (DC) Rated Voltage

 N/A 24 V

Direct Current (DC) Operating Voltage Range

 N/A 9 ~ 28 V

Ingress Protection Rating

 N/A Ingress Protection (IP65)

Case Material

 N/A Acrylonitrile Butadiene Styrene (ABS)

Case Color

 N/A Red

Terminal Material

 N/A Lead Wires

Operating Temperature

 N/A -10 ~ +60 ºC

Weight

 N/A 95 g

Tolerance (±)

 N/A 0.5 mm

Angle Tolerance (±)

 N/A 3 º

Industry Standards

 N/A Restriction of Hazardous Substances (RoHS) 2002/95/EC

Note

Note

 N/A Specifications subject to change or withdrawal without notice.
