Specifications

Manufacturer Stock

 N/A {0}

Brands

 N/A Gowanda

Manufacturer

 N/A Gowanda

Series

 N/A SMRF1812LF

Core Type

 N/A Ferrite

Inductance

 N/A 56 µH

Minimum Q Factor

 N/A 50

Test Frequency

 N/A 2.5 MHz

Minimum Superconducting Radio Frequency (SRF)

 N/A 9 MHz

Maximum Direct Current Resistance (DCR)

 N/A 5.5 Ω

Direct Current (DC) Rating

 N/A 191 mA

Operating Temperature Range

 N/A -55 to +125 ºC

Tolerance (±)

 N/A 5 %

Mounting Type

 N/A RF Surface Mount

Industry Standards

 N/A Restriction of Hazardous Substances (RoHS)

Maximum Weight

 N/A 0.15 g

Tape and Reel Specification

Maximum Pieces/Reel

 N/A 2200

Pitch Between Parts

 N/A 8 mm

Tape Width

 N/A 12 mm

Reel Diameter

 N/A 13 in

Note

Note

 N/A
  • Current Rating is based on a 40 ºC temperature rise at an ambient temperature of 90 ºC
  • Saturation Current is the approximate value that will reduce the initial inductance by 5 %
  • Epoxy-encapsulated for environmental protection and superior strength to withstand all types of reflow soldering
  • Custom designs are available to meet your specific requirements; please contact factory
