Specifications

Manufacturer Stock

 N/A {0}

Brands

 N/A PUI Audio™

Manufacturer

 N/A PUI Audio�, Inc.

Direct Current (DC) Rated Voltage

 N/A 3 V

Direct Current (DC) Operating Voltage Range

 N/A 2 ~ 5 V

Maximum Rated Current

 N/A 30 mA

Minimum Sound Pressure Level (SPL) at 10 Centimeter (cm)

 N/A 80 dBA

Resonant Frequency

 N/A 2700 Hz

Resonant Frequency Tolerance (±)

 N/A 300 Hz

Tone

 N/A Continuous

Operating Temperature

 N/A -30 ~ +70 ºC

Storage Temperature

 N/A -40 ~ +85 ºC

Housing Material

 N/A Liquid Crystal Polymers (LCP)

Terminal Material

 N/A Tin (Sn) Plated Red Copper

Weight

 N/A 1.5 g

Industry Standards

 N/A Restriction of Hazardous Substances (RoHS) 2011/65/EU

Note

Note

 N/A Specifications subject to change or withdrawal without notice.
